    35 Ton Per Batch Corn Mixed Flow Dryer With Efficient Diesel Burner

    Ask Lasest Price
    Brand Name : ZENVO
    Model Number : 5H-35H
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 30 Sets Per Month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    35 Ton Per Batch Corn Mixed Flow Dryer With Efficient Diesel Burner

    35 Ton per Batch Corn Dryer with Efficient Diesel Burner


    Features:
    Mixed flow dryer is widely used for many grains including maize, soybean, wheat, etc.
    Temperature and moisture are monitored automatically during the machine working time;
    Special Air ducts design makes the drying more efficient and energy saving;
    Can be equipped with various heat such as gas, diesel, corn hob,paddy husk etc.
    Multiple safte devices are equipped during the drying for safety sake.
    Controlled by PLC, friendly screen control.


    Model5H-35H
    TypeBatch recycling(mix flow)
    Volume(t)Paddy(560kg/m3)35
    Wheat(700kg/m3)39
    Corn(700kg/m3)39
    Volume m357Weight kg6800
    Dimension(mm)4950×4004×14610 (L×W×H)
    BurnerTypeHot Air Furnace
    IgnitionManual
    FuelBiomass, Coal
    Consumption kg/hHusk≤35
    Coal≤22
    VoltageThree Phase 380V/50HZ
    Output PowerElevator Motor (kW)2.2 (1420 r/min)
    Fan motor (kW)5.5x2
    Paddy discharge motor (kW)0.4 (1410 r/min)
    Upper Paddy discharge motor (kW)0.55 (1390 r/min)
    Dust removal motor (kW)0.37 (2900 r/min)
    Full paddy motor (kW)0.003
    Total (kW)14.523
     Load timePaddy/Corn (min)50—60 / 50—60
    Discharge timePaddy/Corn (min)65—75 / 65—75
    Drying RatePaddy/Corn (%/h)0.8—1.8 / 1.0—2.0
     Safety Devicefull load buzzer,thermal-over relay,temperature controller,hot air temperature sensor,overload protection device,leakage protection device
    Standard Deviceonline moisture monitor,grain temperature sensor, ladder
