    Schneider Electric Box 30 Ton/Batch Recirculating Dryer For Rice Paddy

    Ask Lasest Price
    Brand Name : ZENVO
    Model Number : 5HXG-30
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100 sets per month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Schneider Electric Box 30 Ton/Batch Recirculating Dryer For Rice Paddy

    30 ton per batch recirculating dryer for rice paddy with schneider electric box


    Paddy Dryer Machine Working Principle:
    1. Paddy Loading
    The Paddy is raised to the top of the drying box through the elevator until it is full.
    2. Running(re-circulating):
    The elevator is running all the time. When the Paddy reaches the bottom under the action of self-weight, the elevator raises the Paddy to the top and dries slowly from top to bottom
    3. Drying:
    The hot air passes through the drying layer horizontally. The grain is fully contacted with the drying layer after heating, and achieved drying effect.


    Technical Parameters:

    Model5HXG-155HXG-225HXG-30
    Loading Capacity (Paddy)15T22T30T
    Overall Dimension (L*W*H)2224*3161*9410mm4400*4500*11600mm4500*4300*12700mm
    Weight3000 KGS4155 KGS5630 KGS
    VoltageThree Phase 380V /440V
    Heating MethodIndirect
    Total Motor Power8.503 kW8.903 kW15.853 kW
    Drying Rate0.5~1.2% / h
    Load Time40~50 min45~55 min50~60 min
    Discharge Time55~65 min60~70 min65~75 min
    Safety DeviceOverload saftey device, temperature control device, grain overload alarm, chain fault detector, timer switch, control fuse.

    *The parameters are just for reference. Actual data will differ from grain quality, moisture content, ambient temperature and humudity.

    *Specification is subject to change without notice
