    High Speed Industrial Color Sorter Intelligent CCD Color Sorter Machine

    Ask Lasest Price
    Brand Name : ZENVO
    Model Number : ZVIS8
    Certification : ISO9001
    Price : USD10000~USD39999 per Set
    Supply Ability : 100 Sets per month
    Delivery Time : 15~25 working days
    • Product Details
    • Company Profile

    High Speed Industrial Color Sorter Intelligent CCD Color Sorter Machine

    High speed High Resolution intelligent CCD color sorting machine for industrial use


    - Excellent Sorting Performance


    Advanced image acquisition + intelligent image processing algorithm + high quality ejection system


    - RGB Full color tri-chromatic CCD Image acquisition system


    Top industrial 5400 pixel CCD high speed linear scan imaging sensor

    First-class tailored camera lens for color sorting with a precision identifying 0.01m² tiny defects


    -Super ease of Operation system


    Simple optical system design and accurate in-time auto calibration system


    - Customized image processing algorithm


    Intelligence algorithm integrating image color difference and defect size difference

    Strong industry-grade digital processor, image acquisition and processing in high speed, consistency of signal path and signal reliability is secured for the sorting efficiency


    - Unique Output dust collecting system


    Easy dust output design improves ease of installation for users

    Accurate dust collecting position design to secure sorting room spotless


    - Heavy flow chute design


    Super wide channels to increase the material flow capacity


    - High quality ejector


    Special durable material with no residual magnetism and linear air flow to blow precisely defects

    More than one billion ejections life, low air consumption, low default rate

    Adjustable air flow according to the size and weight of sorted material


    - Reliable lighting configuration


    Most unique intelligent LED cold light source to make identification more precisely

    Anti-interference, more reliability and no need to preheat

    Super long life span, high lighting efficiency


    ModelCapacity
    (t/h)
    Accuracy
    (%)
    Rejecte Ratio
    (Bad:Good)
    Power
    (Kw)
    Working Pressure
    (Mpa)
    Dimension(mm)
    W*D*H
    Weight
    (Kg)
    ZVIS21~3≥99.99≥15:11.26~81380*1638*2163650
    ZVIS32~5≥99.99≥15:12.06~81720*1638*2163980
    ZVIS43~6≥99.99≥15:12.56~82130*1638*21631000
    ZVIS54~7≥99.99≥15:13.06~82400*1638*21631250
    ZVIS65~8≥99.99≥15:13.66~82810*1638*21631550
    ZVIS76~10≥99.99≥15:14.06~82930*1638*21631700
    ZVIS87~12≥99.99≥15:14.56~83380*1638*21631800
    ZVIS107~15≥99.99≥15:15.06~84020*1638*21631980
