Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity

ANHUI ZENVO TECHNOLOGY CO., LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity from wholesalers

    Buy cheap Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity from wholesalers
    • Buy cheap Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity from wholesalers

    Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity

    Ask Lasest Price
    Brand Name : ZENVO
    Model Number : S5
    Certification : ISO9001
    Price : Negotiable
    Supply Ability : 50 sets per month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity

    Intelligent CCD Raisin Color Sorter Machine with 5 ton per hour capacity

    Advantages:


    The color sorter adopt full color 5400+pixel high performances CCD sensors with the definition up to 0.01mm.
    The sorter adopts high quality special industrial lenses designed and manufactured for color detection.
    The high speed DSP technology provides the sorter with fast detection and high identification rate.
    Master control system adopts ARM high-end embeded processor to enhance and control the speed and color selection precision effectively.
    Overall unit adopts intelligent closed-loop control system.
    The operation interface adopts industrial grade touch screen and features simple parameter setting and easy operation.
    High speed ejector is used to ensure quick response, low power consumption and long service life.
    The sorter uses intelligent temperature and air pressure control technology in order to ensure the best operative mode for the whole machine.


    Product Parameters

    ModelChannels(t/h)ThroughputAccuracy(%)Optimized CarryoverPower(Kw)Dimension(mm)(L*W*H)Weight(Kg)
    S1641~299.99≥12:11.0920*1500*1870330
    S42562.5~699.99≥12:12.41970*1580*18701180
    S53203.5~899.99≥12:12.92290*1580*18701330
    S63844.5~1099.99≥12:13.42610*1580*18701480
    S74485.5~1299.99≥12:13.92930*1580*18701630
    S85126~1499.99≥12:14.43250*1580*18701780

    The above parameters are for reference only and may vary as per types of raw materials and contamination rate.

    Specific parameters will be altered according to different material and contamination rate on site of customers.


    Advantages:

    Tri-chromatic CCD Image Acquisition System

    5400 pixel, identify 0.01mm2 defects.

    Intelligent Image Processing Algorithm

    ALTERA FPGA, intelligent & speedy .

    Premium Light System

    LED lighting, higher stability.

    Advanced Feeding System

    Special anodized chute, higher capacity.

    Excellent Rejection Rate

    Quality image acquisition& processing& nozzle system



    Quality Intelligent CCD Raisin Sorting Machine / Grain Sorting Machine With 5 Ton Per Hour Capacity for sale
